Note : Standard magnification from 7X to 45X and working distance is tabulate above at different job height. With high eye point and wide field eyepiece 10X.
| Sr.No. | Magnification | Job height | Working Distance (Between Top surface of object and bottom of microscope head) |
| 1. | 7X | 0 mm | 97 mm |
| 2. | 45X | 0 mm | 89 mm |
| 3. | 7X | 50 mm | 146 mm |
| 4. | 45X | 50 mm | 139 mm |
| 5. | 7X | 105 mm | 198 mm |
| 6. | 45X | 105 mm | 193 mm |
| 7. | 7X | 150 mm | 245 mm |
| 8. | 45X | 150 mm | 238 mm |
| 9. | 7X | 190 mm | 283 mm |
| 10. | 45X | 190 mm | 275 mm |
